Panasonic KX-NS500 Getting Started

1.1 Outline
This manual provides basic information about starting the PBX and using IP telephones.
Note
• In this manual, the suffix of each model number
(e.g., KX-NS500NE) is omitted unless necessary.
• In this manual, terms are defined as follows:
IP-PT
IP Proprietary Telephone
SIP extension
Extensions of the PBX which use Session Initiation Protocol for communication.
SIP phone
KX-UT series SIP phone
Panasonic SIP Phone (P-SIP e.g,. KX-HDV series)
IP conferencing phone (e.g., KX-NT700)
Third party SIP phone (SIP hardphones/SIP softphones)
• Operation of the KX-NS0154 depends on the PBX software file version and the firmware version of the
KX-NS0154. You can confirm the compatibility on the Panasonic Web site:
http://panasonic.net/pcc/support/pbx/
About the Other Manuals
User Manual
Provides operating instructions for end users using IP-PTs, SIP phones, SLTs, PSs, or DSS Consoles.
Installation Manual
Provides instructions for installing the hardware and maintenance of the PBX.
Feature Guide
Describes all basic, optional and programmable features of the PBX.
PC Programming Manual
Provides step-by-step instructions for performing system programming using a PC.
PT Programming Manual
Provides step-by-step instructions for performing system programming using a PT.
Open Source Software
This product uses Open Source Software. For details, click the Information button in Web Maintenance
Console.
4 Getting Started
1.1 Outline

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
