14 Cursor buttons
15 Aspect ratio selector switch
16 Microphone
17 Zoom lever
18 Motion picture button
19 Flash open switch
20 Hot shoe cover
Keep the hot shoe cover out of reach
of children to prevent swallowing.
21 Mode dial
22 Shutter button
23 Camera ON/OFF switch
24 [HDMI] socket
25 [AV OUT/DIGITAL] socket
26 Lens ring front
27 Lens barrel
/[FOCUS] button
/Function button
Assign Menu to button. It is convenient to register a Menu that is used
often.
[FILM MODE]/[QUALITY]/[METERING MODE]/[WHITE BALA
NCE]/
[AF MODE]/[I.EXPOSURE]/[GUIDE LINE]/[ REC AREA]/
[REMAINING DISP.]/[FLASH]/[AUTO BRACKET]/[ASPECT BRACKET]
/Self-timer button
/ISO
15 16 17 18
19 20 21 22 23
28 Tripod receptacle
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
29 Speaker
Do not cover the speaker with your
fingers.
30 Card/Battery door
31 Release lever
32 DC coupler cover
When using an AC adaptor, ensure that the
Panasonic DC coupler and AC adaptor are used.
Always use a genuine Panasonic AC adaptor (optional).
We recommend you use a battery with sufficient battery
power or the AC adaptor when recording motion pictures.
If while recording motion pictures using the AC adaptor
and the power supply is cut off due to a power outage
or if the AC adaptor is disconnected etc., the motion
picture being recorded will not be recorded.
32
28 29
31
30
