8.3. Disassembly Procedure
No. Item Fig Removal
1 Rear Case Unit (Fig. D1) Card
Battery
3 Screws (A)
1 Screw (B)
(Fig. D2) Shoe Spring
2 Screws (C)
FP9003(Flex)
FP9010(Flex)
Rear Case Unit
2 LCD Unit (Fig. D3) 2 Locking tabs
2 Hanging parts
LVF Jack Holder
Capton Tape
1 Locking tab
2 Hanging parts
LCD Holder
LCD Unit
3 Front Case Unit (Fig. D4) FP9006(Flex)
3 Screws (D)
4 Screws (E)
1 Screw (F)
2 Screws (G)
Front Case Unit
4 Top Operation Unit (Fig. D5) 1 Screw (H)
FP9002(Flex)
3 Locking tabs
Top Operation Unit
5 Main P.C.B. (Fig. D6) Tape
FP9001(Flex)
FP9005(Flex)
FP9007(Flex)
FP9008(Flex)
FP9009(Connector)
1 Screw (I)
2 Locking tabs
Main P.C.B.
6 Lens Unit (Fig. D7) 3 Locking tabs
Tripod
Lens Unit
7 Battery P.C.B. (Fig. D8) 1 Screw (J)
1 Hanging part
Battery P.C.B.
8 Gyro P.C.B. (Fig. D9) 2 Hanging parts
Gyro P.C.B.
9 Speaker (Fig. D10) Speaker Tape
Speaker
10 LVF P.C.B. (Fig. D11) 2 Screws (K)
FP9971(Flex)
1 Screw (L)
Shield Plate
LVF P.C.B.
11 Top P.C.B. (Fig. D12) AF Panel Light
2 Screws (M)
FP9951(Flex)
2 Locking tabs
Top P.C.B.
(Fig. D13) NOTE: (When Installing)
12 Flash Unit (Fig. D14) 5 Locking tabs
3 ribs
Flash Unit
13 Flash P.C.B. Unit (Fig. D15) P8001(Connector)
P8002(Connector)
Strap Holder(R)
2 Locking tabs
1 Rib
FLK Unit
FL Tape(A)
Flash P.C.B. Unit
14 Lens Ornament Unit (Fig. D16) 3 Screws (N)
Front Plate
Lens Ornament Unit
15 AF/MF-Aspect FPC (Fig. D17) 2 Screws (O)
AS Click Spring
FC Click Spring
Focus Sheet
Focus Knob
Aspect Sheet
AS Knob
(Fig. D18) Lens Ring Front
1 Screw (P)
Lens Ornament
3 Screws (Q)
AF/MF-Aspect FPC
16 Battery Case (Fig. D19) 3 Locking tabs
Battery Out Spring
Battery Case
17 Battery Door Unit (Fig. D20) Battery Door Shaft
Battery Door Spring
Battery Door Unit
18 Jack Door (Fig. D21) Jack Door Shaft
Jack Door
No. Item Fig Removal
