S-2
S2. Voltage Chart
S2.1. Gyro P.C.B.
Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
REF No. PIN No. POWER ON
IC7201 1 -
IC7201 2 -
IC7201 3 -
IC7201 4 0
IC7201 5 0
IC7201 6 0
IC7201 7 0
IC7201 8 3.1
S2.2. BAT P.C.B.
REF No. PIN No. POWER ON
IC7301 1 -
IC7301 2 -
IC7301 3 -
IC7301 4 0
IC7301 5 1.4
IC7301 6 1.4
IC7301 7 0
IC7301 8 3.1
S2.3. Flash P.C.B.
REF No. PIN No. POWER ON
IC8001 1 0
IC8001 2 0
IC8001 3 0
IC8001 4 0
IC8001 5 3.6
IC8001 6 0
IC8001 7 0
IC8001 8 0
IC8001 9 3.1
IC8001 10 4
IC8501 1 -
IC8501 2 0
IC8501 3 3
IC8501 4 3
S2.4. Top P.C.B.
REF No. PIN No. POWER ON
Q9951 S 0
Q9951 D 3
Q9951 G 0
