Panasonic TH-65PF30U User Manual

0
0
0
1/2
SOUND
NORMAL
NORMALIZE
STANDARD
OFF
TREBLE
AUDIO MENU
BALANCE
BASS
0
MID
SURROUND
34
SOUND Adjustment
1
Press to display the SOUND menu.
Press to select the menu to adjust.
Select the desired level by listening to the sound.
Press to exit from adjust mode.
2
Select to adjust each item.
While the “SOUND” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION
(
) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.
Helpful Hint ( /
NORMALIZE
Normalization)
3
SDI SOUND OUTPUT
This menu is available only when selecting a slot that any of the following terminal boards is installed:
HD-SDI Terminal Board with audio (TY-FB10HD), Dual Link HD-SDI Terminal Board (TY-FB11DHD), or Dual HD-SDI
Terminal Board for 3D (TY-FB30DHD3D)
2/2
SOUND OUT
LEFT CHANNEL
RIGHT CHANNEL
CHANNEL 1
CHANNEL 1
OFF
LEVEL METER
OFF
SDI SOUND OUTPUT
Item Details
LEFT CHANNEL
CHANNEL 1 to CHANNEL 16
Selects left audio channel.
RIGHT CHANNEL
CHANNEL 1 to CHANNEL 16
Selects right audio channel.
SOUND OUT
ON
OFF
ON: Enables audio output.
OFF: Disables audio output.
LEVEL METER
OFF
1-8CH 9-16CH
Sets audio channels to show in the audio level meter.
8 channels are displayed in the audio level meter; 4 channels
each on both right and left sides of the display.
OFF: Hides the audio level meter.
1-8CH: Displays the audio level meter (1-8ch)
9-16CH : Displays the audio level meter (9-16ch)
Note: BASS, MID, TREBLE and SURROUND settings are memorized separately for each AUDIO MENU.
Item Details
AUDIO MENU
STANDARD: Emits the original sound.
DYNAMIC: Accentuates sharp sound.
CLEAR: Attenuates human voice.
BASS Adjusts low pitch sounds.
MID Adjusts normal sounds.
TREBLE Adjusts pitch sound.
BALANCE Adjusts left and right volumes.
SURROUND Select ON or OFF.
