Preset Signals
This unit can display the video signals shown in the table below.
●
The contents of HDMI signal in the Plug and Play-supported signal column are as follows.
1: 4K/60p, 2: 4K/30p, 3: 2K
Corresponding
signal
Resolution (Dot)
Scanning frequency
Dot clock
frequency
(MHz)
Format
*
2
Plug and Play-supported
signal
*
4
Horizontal
(kHz)
Vertical
(Hz)
HDMI
DVI-D/
PC
1 2 3
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.73 59.94 V
PAL/PAL-N/SECAM 720 x 576i 15.63 50.00 V
480/60i 720 x 480i 15.73 59.94 13.50 Y
576/50i 720 x 576i 15.63 50.00 13.50 Y
480/60i 720 (1440) x 480i
*
1
15.73 59.94 27.00 D/H ○ ○ ○
576/50i 720 (1440) x 576i
*
1
15.63 50.00 27.00 D/H ○ ○ ○
480/60p 720 x 483 31.47 59.94 27.00 Y/D/H ○ ○ ○
576/50p 720 x 576 31.25 50.00 27.00 Y/D/H ○ ○ ○
720/60p 1280 x 720 45.00 60.00 74.25 Y/D/H ○ ○ ○
720/50p 1280 x 720 37.50 50.00 74.25 Y/D/H ○ ○ ○
1080/60i 1920 x 1080i 33.75 60.00 74.25 Y/D/H ○ ○ ○
1080/50i 1920 x 1080i 28.13 50.00 74.25 Y/D/H ○ ○ ○
1080/24p 1920 x 1080 27.00 24.00 74.25 Y/D/H ○ ○ ○
1080/24PsF 1920 x 1080i 27.00 48.00 74.25 Y/D/H
1080/25p 1920 x 1080 28.13 25.00 74.25 Y/D/H ○ ○ ○
1080/30p 1920 x 1080 33.75 30.00 74.25 Y/D/H ○ ○ ○
1080/60p 1920 x 1080 67.50 60.00 148.50 Y/D/H ○ ○ ○
1080/50p 1920 x 1080 56.25 50.00 148.50 Y/D/H ○ ○ ○
2K/24p 2048 x 1080 27.00 24.00 74.25 D/H
2K/25p 2048 x 1080 28.13 25.00 74.25 D/H
2K/30p 2048 x 1080 33.75 30.00 74.25 D/H
2K/48p 2048 x 1080 54.00 48.00 148.50 D/H
2K/60p 2048 x 1080 67.50 60.00 148.50 D/H
2K/50p 2048 x 1080 56.25 50.00 148.50 D/H
3840 x 2160/24p 3840 x 2160 54.00 24.00 297.00 H ○ ○
3840 x 2160/25p 3840 x 2160 56.25 25.00 297.00 H ○ ○
3840 x 2160/30p 3840 x 2160 67.50 30.00 297.00 H ○ ○
3840 x 2160/60p 3840 x 2160 135.00 60.00 594.00 H ○
3840 x 2160/50p 3840 x 2160 112.50 50.00 594.00 H ○
4096 x 2160/24p 4096 x 2160 54.00 24.00 297.00 H ○ ○
4096 x 2160/25p 4096 x 2160 56.25 25.00 297.00 H ○ ○
4096 x 2160/30p 4096 x 2160 67.50 30.00 297.00 H ○ ○
4096 x 2160/60p 4096 x 2160 135.00 60.00 594.00 H ○
4096 x 2160/50p 4096 x 2160 112.50 50.00 594.00 H ○
640 x 400/70 640 x 400 31.47 70.09 25.18 R/D/H
640 x 400/85 640 x 400 37.86 85.08 31.50 R/D/H
640 x 480/60 640 x 480 31.47 59.94 25.18 R/D/H ○ ○ ○ ○
640 x 480/67 640 x 480 35.00 66.67 30.24 R/D/H
640 x 480/73 640 x 480 37.86 72.81 31.50 R/D/H
640 x 480/75 640 x 480 37.50 75.00 31.50 R/D/H
640 x 480/85 640 x 480 43.27 85.01 36.00 R/D/H
800 x 600/56 800 x 600 35.16 56.25 36.00 R/D/H
800 x 600/60 800 x 600 37.88 60.32 40.00 R/D/H ○ ○ ○ ○
800 x 600/72 800 x 600 48.08 72.19 50.00 R/D/H
800 x 600/75 800 x 600 46.88 75.00 49.50 R/D/H
800 x 600/85 800 x 600 53.67 85.06 56.25 R/D/H
832 x 624/75 832 x 624 49.72 74.55 57.28 R/D/H
852 x 480/60 852 x 480 31.47 59.94 34.24 D/H
1024 x 768/50 1024 x 768 39.55 50.00 51.89 D/H
