Parkside PAFS 550 A1 User Manual

PAFS 550 A1
■ 14
│
GB
│
IE
Cleaning the inlet valve
WARNING! RISK OF INJURY!
Before carrying out any work on the
appliance, switch it off, disconnect
the mains plug and depressurise the
appliance!
NOTE
► If there are irremediable problems with the
paint suction, you should clean the inlet
valve h or replace it, if necessary.
♦ Disconnect the suction hose 2 from the appli-
ance.
♦ Remove the inlet valve h using an adjustable
spanner.
♦ Remove the O-ring g, ball f, washer d and
spring s (see fig. G).
♦ Clean the parts thoroughly using suitable
cleaning agents. Replace them, if necessary.
NOTE
► You can obtain replacement parts not listed
here from the service hotline given in the
section "Service".
♦ Grease the O-ring g.
♦ Replace the parts into the inlet valve h
(see fig. G).
♦ Screw the inlet valve h back into the appli-
ance. Tighten it using an adjustable spanner.
Cleaning the connecting thread
WARNING! RISK OF INJURY!
Before carrying out any work on the
appliance, switch it off, disconnect
the mains plug and depressurise the
appliance!
If you are still experiencing a poor spray pattern
after cleaning the nozzle, you should clean the
connecting thread r.
♦ Remove the high-pressure hosew from the
connecting threadr using an adjustable
spanner. Counter the nut of the connection
thread r with a second adjustable spanner.
♦ Loosen the fastening screw j with a Phillips
screwdriver (not supplied).
♦ Loosen the hex screw k with a 2 mm hex key
(not supplied).
♦ Remove the connection thread r using an
adjustable spanner.
♦ Clean the connecting thread r using a suitable
cleaning agent. Replace it, if necessary.
♦ Screw the connecting thread r back into the
appliance and tighten it using an adjustable
spanner.
♦ Retighten the fastening screw j with a Phillips
screwdriver.
♦ Turn the hex screw k with a 2 mm hex key.
Storage and transportation
■ Store the appliance in a dry, dust-free location.
■ Transport the appliance only when you have
taken it completely out of service. Transport
the appliance in such a way that it cannot be
damaged or soiled. Preferably, use the original
packaging.
