Parkside PMRDA 20-Li A1 User Manual

GB MT
44
19 Screw
20 Blade
21 Baseplate
22 Charging unit
23 Cover
24 Bushing
25 Charging socket
26 Contact socket +
27 Contact socket -
28 LED
29 Groove
30 Charging prongs
31 Operating range indicator
32 Battery compartment
33 Battery
34 Blade bolt
Description of functions
The lawn mower has a rotating cutting tool
parallel to the cutting plane. It is equipped
with a high-performance electric motor, a
robust plastic housing and a safety switch.
In addition, the device has infi nite height
adjustment and smooth-running wheels.
The lawn mower can optionally be connect-
ed and controlled with the Lidl Home App.
Please refer to the descriptions below for
information on how the operating elements
work.
Technical data
Lawn mower ........PMRDA 20-Li A1
Motor voltage U ......................... 20 V
Drive speed ............................. 1.2 km/h
Protection type .................................IPX4
No-load rotation speed
(max. speed) .......................... 3100 rpm
Cutting circle .............................220 mm
Cutting height ....................... 25 - 60 mm
Slope/incline/gradient
on the terrain .............. max. 47 % (25°)
At a distance of 1 m from the boundary
wire .............................. < 10 % (5.7°)
Blade.............3 with double-sided blades,
reversible - item no. 92000001
Max. work area ........................ 1000 m
2
Weight (without charging station and
accessories) m ............................. 8.8 kg
Mowing time per battery charge
(4 Ah) .............................approx. 70 min
Recommended operating time (hrs) per
day*
200 m
2
................................ 3.5 hours
400 m
2
................................... 7 hours
600 m
2
................................. 10 hours
800 m
2
.............................. 13.5 hours
1000 m
2
............................... 16 hours
Sound pressure level
(L
pA
) ..............59,9 dB(A), K
pA
= 1.88 dB
Sound power level (L
WA
)
guaranteed ...........................66 dB(A)
measured ..... 63.8 dB(A), K
WA
= 1.88 dB
* The times actually required depend on the
type of grass, the growing conditions, the
humidity and the fl atness of the lawn area.
Power adapter ...................... SF-20
Input voltage/
Input ..... 220-240 V~; 50/60 Hz; 1.5 A
Output voltage/
Output .................DC 22,0 V
; 2.5 A
Frequency range of the
boundary wire ............100 Hz-148.5 kHz
Maximum transmission power of the
boundary wire ........... 50 dBA/m at 10 m
WIFI frequency range ..2400-2483.5 GHz
Maximum WLAN transmitting
power .....................................17.5 dBm
Bluetooth WIFI
Frequency range .........2400-2483.5 GHz
Maximum Bluetooth transmission
power ..........................................7 dBm
Protection class ................................
II
Protection type ................................ IP65
Max. outdoor temperature (t
a
) ......... 50°C
