Parkside PTBM 500 E5 User Manual

17
CY
IE NI
• Clean the ventilation openings and the
surface of the device with a soft brush
or cloth.
• Remove chips, dust and dirt with a va-
cuum cleaner if necessary.
• Lubricate moving parts regularly.
• Do not allow lubricants to come into
contact with switches, V-belts, pulleys
and drill lifting arms.
H
Maintenance
Repeat the maintenance after every
5 hours of operation.
1. Release the locking bolt (
A
11) on the
gear cover (3).
2. Open the gear cover (3).
3. Release the retaining screw (
A
12) on
the motor unit (
A
13).
4. Using the lever (
E
33), slide the motor
unit (
A
13) forwards a little to release
the load on the V-belts (
E
29).
5. Remove both V-belts (
E
29).
6. Remove the middle drive disc (37) and
its retainer (38).
7. Clean the bearing point retainer (39+40)
and grease this with a commercially
available multi-purpose grease.
8. Re-insert the retainer (38) and the drive
disc (37). Tighten the V-belts (
E
29)
again.
9. Using the lever (
E
33), slide the motor
unit (
A
13) backwards to re-tighten the
V-belts (
E
29).
10.The V-belts (
E
29) are correctly tensi-
oned when they give way slightly when
pressed.
11.Re-tighten the retaining screw (
A
12)
of the motor unit (
A
13).
12.Close the gear cover (3). Fasten the lo-
cking bolt (
A
11) on the gear cover .
Storage
• Store the appliance in a dry place well
out of reach of children.
• The device can be relocated over a
short distance with two people. Reloca-
ting the device over a longer distance
generally has to take place with a trans-
port aid.
Transport
Do not carry the bench drill
holding it on the motor unit.
Caution! Hot surface. There is a
risk of burns. Only transport the
machine when the motor unit
(
A
13) has cooled down com-
pletely.
If possible, carry the bench drill together
with another person. Grip the baseplate
(
A
17) with one hand and stabilise the
machine on the drive cover (
A
3) with the
other hand.
Waste disposal
and environmental
protection
Be environmentally friendly. Remove the
battery from the device and take the de-
vice, battery, accessories and packaging
for environmentally friendly recycling.
Electrical machines do not belong
with domestic waste.
• Hand over the device at an utilization
location. The plastic and metal parts
employed can be separated out and
thus recycled use can be implemented.
Ask our Service-Center for details.
