26
Proper use
This device is only intended for the follow-
ing use:
• Cutting and trimming hedges, bushes
and ornamental shrubs.
The device is intended for use by adults.
Children under the age of 16 may not use
the device, except under supervision.
Use of the device in the rain or a damp
environment is prohibited.
Any other use that is not expressly permit-
ted in this instruction manual may pose
a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
The device is part of the X20VTEAM
series and can be operated with bat-
teries of the X20VTEAM series. Bat-
teries of the X20VTEAM series may
only be charged using chargers of the
X20VTEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Cordless Extendable Hedge Trimmer
20V
• Blade encasing
• Carrying strap
• Allen key
• Translation of the original instructions
The rechargeable battery and
charger are not included in deliv-
ery.
Overview
The illustrations for the
device can be found on
the front and back fold-out
page.
1Safety cutter bar
2Motor head
3Locking button
4Coupling nut
5Lock (Extension arm)
6Tubular shaft
7Coupling nut
8Eyelet
9Push-fit lock
10Carrying strap
11Switch lock
12Handle
13On/Off switch
14Storage
15Battery holder
16Tubular shaft
17Insulated gripping surface
18Extension arm
19Blade encasing
20Allen key
21Battery
22Battery release
23Button
24Charge level indicator
25Battery charger
(Fig.A)
26Threaded coupling
27Lug
