Parkside PTHSA 20-Li C4 User Manual

GB
27
(Fig.B)
28Threaded coupling
29Lug
(Fig.D)
30Hexagon socket screw
Description of functions
Das Gerät besitzt als Antrieb einen
Elektromotor. Als Schneideinrichtung
besitzt das Gerät einen doppelseiti-
gen Sicherheitsmesserbalken. Beim Sch-
neidvorgang bewegen sich die Sch-
neidzähne linear hin und her. Der An-
schlagschutz an der Spitze des Sich-
erheitsmesserbalkens verhindert unan-
genehme Rückschläge beim Auftreffen auf
Wände, Zäune usw. Die Funktion der Be-
dienteile entnehmen Sie bitte den nachfol-
genden Beschreibungen.
Technical data
Cordless Extendable Hedge Trim-
mer 20V ................PTHSA 20-Li C4
Rated voltage U .............................20V ⎓
Weight with battery (20V, 2Ah) ...3.8kg
Weight (only motor unit) ..................2.1 kg
No-load rotation speed n
0
.....1150 min
−1
Protection type .....................................IPX0
Cutting length ................................410 mm
Blade tooth spacing ........................16 mm
Branch diameter ..............................12 mm
Sound pressure level (L
pA
)
......................................77.1 dB; K
pA
=3dB
Sound power level (L
WA
)
–Measured .........88.1 dB; K
WA
=2.74 dB
–Guaranteed ...................................92 dB
Vibration (a
h
)
–Handle ..............≤2.5 m/s²; K=1.5m/s²
–Insulated gripping surface
...............................≤2.5 m/s²; K=1.5m/s²
Battery .................................................Li-Ion
Temperature ...................................≤50 °C
– Charging ................................4 – 40°C
– Operation .........................−20 – 50°C
– Storage ..................................0 – 45°C
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1
–frequency band ....2400–2483.5 MHz
–transmitted power ...................≤ 20 dBm
Levels of noise and vibration were determ-
ined according to the standards and regu-
lations in the declaration of conformity.
The specified total vibration value and the
stated noise emission value have been
measured according to a standardised
test method and can be used to compare
one power tool with another. The specified
total vibration value and the stated spe-
cified noise emission value can also be
used for a provisional assessment of the
load.
WARNING!The vibration and noise
emissions may deviate from the specified
values during actual use of the power tool,
depending on how the power tool is be-
ing used. Try to keep the exposure to vi-
brations as low as possible. An example
of a measure to reduce vibration exposure
is limiting the working hours. All parts of
the operating cycle have to be considered
while doing so (for example, times when
the power tool is switched off and times
when it is switched on but running without
any load).
Charging time
The device is part of the X20VTEAM
series and can be operated with bat-
teries of the X20VTEAM series. Bat-
teries of the X20VTEAM series may
only be charged using chargers of the
X20VTEAM series.
We recommend that you operate
this appliance with the following bat-
teries only: PAP 20 B1, PAP 20 B3,
Smart PAPS 204 A1, Smart PAPS 208 A1
