52 GB/IE
Push in the trigger
12
to open the current
clamp jaws
1
.
Place the current clamp jaws
1
around the
conductor to be measured.
Close the current clamp jaws
1
.
Position the conductor in the middle between
both – markings on the current clamp jaws
(Fig. C).
The reading is shown in the display
6
.
NOTE: Only 1 conductor should be clamped
(Fig. C). Measuring 2 or more conductors at
the same time will result in a wrong reading.
Position the conductor at the centre of the
jaws
1
. This reduces the likelihood of a
measurement error.
m WARNING: Risk of electric shock!
Maximum measurable current: 600 A.
Do not measure currents on a circuit with a
voltage of > 600 V.
Measuring resistance
Before measuring:
–
Disconnect all power at the circuit to be tested.
–Discharge all capacitors.
Connect
–the black test probe
9
to COM
8
and
–the red test probe
9
to
7
.
