OPERATING THE PUMP 3/20
Press menu button to access menus
Date
Pump Address (1-16) - Default: 1
Screen Contrast (1-5) - Default: 3
Language
Manual
Schedule
Egg Timer
Set Speed - Default Spd 1-2: Manual
Set Speed
Set Start Time
Set Stop Time
Set Speed - Default Spd 3-4: Egg Timer
Time
Disabled / Enabled - Default: Enabled
Schedule
Set Speed
Set Start Time
Set Stop Time
Disabled
Default: Disabled
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
Set Speed (450 RPM - 3450 RPM) Default 1000 RPM
SETTINGS
MENU
SPEED 1-8
EXT CONTROL
THERMAL MODE
Time
Hour Format
Months (1-12)
Days (1-31)
Years (2000-2050 Plus)
Hours (24hr Mode: 0-23) (12hr Mode: 1-12 AM & PM)
Minutes (0-60)
AM/PM - Default: AM/PM
Min Speed (450-1700 RPM) - Default: 450 RPM
Max Speed (1900-3450 RPM) - Default: 3450 RPM
English - Default: English
Português
Deutsch
Italiano
Nederlands
Français
Español
Temperature Unit Fahrenheit - Default F°
Celsius C°
Firmware Version
Password
Disabled - Default: Disabled
Enabled
Password Timeout (1 min. to 6 hrs.) - Default: 1 minute
Set Password (0000 - 9999) - Default: 1234
Stop Delay (0 min. to 10 min.) Default: 0 minutes
24 Hour
Device
Set Date and Time
Set Speed Max/Min
Speed 1-4
Speed 5-8
Disabled/Enabled
Set Speed
Pump Temperature
Set Speed (450-3450 RPM) - Default: 750 RPM
Set Speed (450-3450 RPM) - Default: 1500 RPM
Set Speed (450-3450 RPM) - Default: 2350 RPM
Set Speed (450-3450 RPM) - Default: 3110 RPM
Program 1
Program 2
Program 3
Program 4
Set Speed (450-3450 RPM) Default: 3450 RPM
Quick Clean Duration (1 min. to 10 hrs.) Default: 10 minutes
Time Out Duration (1 min. to 10 hrs.) Default: 3 hours
FEATURES
Quick Clean
Time Out
(1 min. to 30 min.) Default: 11 minutes
Disabled / Enabled - Default: Enabled
(1 - 10) Default: 5
(1 sec. to 10 min.) Default: 20 seconds
PRIMING
Disabled/Enabled
Max Priming Time
Priming Range
Priming Delay
Priming Speed
Set Speed (2400-3450 RPM) - Default: 3450 RPM
Alarm Log (1-10)
Stop Delay (0 min. to 10 min.) Default: 0 minutes
Stop Delay (0 min. to 10 min.) Default: 0 minutes
Stop Delay (0 min. to 10 min.) Default: 0 minutes
INTELLIFLO
®
VSD2 PUMP MENUS
