INTELLIFLO
®
VSF Variable Speed and Flow Pump Installation and User’s Guide
8
INTELLIFLO
®
VSF Variable Speed and Flow Pump Installation and User’s Guide
Operator Control Panel: Pump Menu Guide
Press MENU button to access menus
Date
SETTINGS
MENU
Time
Hour Format
Months (1-12)
Days (1-31)
Years (2010-2100 Plus)
Hours (24hr Mode: 0-23) (12hr Mode: 1-12 AM & PM)
Minutes (0-60)
AM/PM - Default: AM/PM
Set Min Speed (450-1700 RPM) - Default: 450 RPM
Set Max Speed (1900-3450 RPM) - Default: 3450 RPM
24 Hour
Set Min Flow (20-70 GPM) - Default: 20 GPM
Set Max Flow (80-140 GPM) - Default: 140 GPM
Flow Limit Speed (Disabled / Enabled) - Default: Disabled
Max Pressure (1-50 PSI) - Default: 30 PSI
Pressure Limit Speed (Disabled / Enabled) - Default: Disabled
Date and Time
Min/Max
(pages 10-13)
Pump Address (1-16) - Default: 1
Contrast Level (1-5) - Default: 3
Language
Manual
Schedule
Egg Timer
Set Speed or Flow (450-3450 RPM or 20-140 GPM) - Default Program 1-2: Manual
Schedule
Disabled
PROGRAM 1-8
English - Default: English
Português
Deutsch
Italiano
Nederlands
Français
Español
Temperature Unit Fahrenheit - Default: F°
Celsius C°
Firmware Version
Password
Disabled - Default: Disabled
Enabled
Password Timeout (1 min. to 6 hrs.) - Default: 1 hour
Set Password (0000 - 9999) - Default: 1234
Fast - Default: Fast
Medium
Slow
Fast - Default: Fast
Medium
Slow
Type (Speed / Flow)
Type (Speed / Flow)
Start Time
Stop Time
Default: Disabled
Duration
Type (Speed / Flow)
Start Time
Stop Time
Type (Speed / Flow)
Device
Program 1-4
Program 5-8
(pages 14-15)
Alarm Log (1-10)
Flow Unit GPM - Default: GPM
LPM
Pressure Unit PSI - Default: PSI
BAR
Ramping Ramp Up
Ramp Down
MENU TREE
CONTINUES TO
Set Speed or Flow (450-3450 RPM or 20-140 GPM)
Set Speed or Flow (450-3450 RPM or 20-140 GPM) - Default Program 3-4: Egg Time
Set Speed or Flow (450-3450 RPM or 20-140 GPM)
M
3
/ H
To Next Page
