Set Programs in Manual Mode
(Programs 1-4 Only)
1. Press Menu.
2. Use Up or Down arrows to scroll to “Program 1-8”,
then press Select.
3. Use Up or Down arrows to find the program (1-4)
you wish to edit, then press Select.
4. "Operation Mode" will display. Press Select and
use the Up or Down arrow to scroll to "Manual".
Press Save.
5. Use the Up or Down arrow to scroll to "Set Type".
Press Select and use the Up or Down arrow to
choose between "Speed" or "Flow". Press Save.
6. Use the Up or Down arrow to scroll to "Set Speed/
Flow". Press Select and use the Up or Down
arrow to adjust the speed or flow settings.
7. Press Save to save the new speed or flow setting.
Set Programs in Egg-Timer Mode
(Programs 1-4 Only)
1. Press Menu.
2. Use Up or Down arrows to scroll to “Program 1-8”,
then press Select.
3. Use Up or Down arrows to find the program (1-4)
you wish to edit, then press Select.
4. "Operation Mode" will display. Press Select and
use the Up or Down arrow to scroll to "Egg Timer".
Press Save.
5. Use the Up or Down arrow to scroll to "Set Type".
Press Select and use the Up or Down arrow to
choose between "Speed" or "Flow". Press Save.
6. Use the Up or Down arrow to scroll to "Set Speed/
Flow". Press Select and use the Up or Down
arrow to adjust the speed or flow settings. Press
Save.
7. Now press the Down arrow ("Egg Timer Duration"
will display) and press Select to change. Use the
Up or Down arrows to adjust the time.
8. Press Save to save the new time setting.
Manual Mode
Menu Screen
Egg Timer
Menu Screen
12:15p
Manual
12:15p
Egg Timer
Operation Mode
Operation Mode
Pump Menu: Programs 1-8
Pump Operating Modes
This pump can be programmed in three different
modes:
Programs 1-4 can be programmed in all three modes.
Programs 5-8 can only be programmed in Schedule
mode since there are no buttons on the control panel
for Programs 5-8. The default setting for Programs 5-8
is “Disabled”.
Manual
Assigns a speed or flow to one of the four Program
buttons on the control panel. This mode can only be
used for programs 1-4. Programs 1 and 2 are Manual
by default.
To operate in Manual mode, press one of the four
program buttons and then press the Start/Stop
button. The pump will run the assigned speed or flow
assigned to that program button.
Egg Timer
Programs 1-4 can be programmed to run at a certain
speed or flow and for a duration of time once a
program button is pressed.
Programs 3 and 4 are Egg Timers by default. If you
desire a different method of operation, programs 3
and 4 can be changed to Manual mode in the control
menu.
To operate in Egg Timer mode, press a program button
and then press Start/Stop. The pump will run that
setting for the set amount of time and then turn off.
Schedule
Programs 1-8 start and stop at a specific time during
a 24 hour period. Speeds or flows programmed in
Schedule mode will override any manually selected
speed or flow once the next Schedule command
commences.
Set Flow
Schedule
Egg Timer
Set Type
Set Flow
Set Type
Set Start Time
Set Stop Time
Set Flow
Set Flow
Set Type
Set Flow
Set Flow
Program 1-4
Schedule
Default: Disabled
Set Type
Set Start Time
Set Flow
Set Flow
Program 5-8
Program Menu Tree Options
PROGRAM 1-8
MENU
To Next Page
