Persistent Systems Wave Relay MPU5 User Manual

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
28
PHYSICAL SETUP: POWER
1
If you are using a battery, make
sure that the battery is charged.
2
Align the circular three pin connector on
the power source with the circular three
pin connector on the bottom of the MPU5.
3
Push the connectors together. Make sure
the connector is seated properly.
Connecting Power

Persistent Systems Wave Relay MPU5 Specifications

General

Modulation	QPSK
Power Output	Up to 2W
Interfaces	Ethernet, USB, Serial
Encryption	AES-256
Dimensions	Varies by model
Weight	Varies by model
Battery Life	Varies by model
Networking	MANET
