© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
36
PHYSICAL SETUP: SIDE CONNECTORS
1
The 22-Pin connector on
every cable is keyed so
that it will only attach to
a compatible side con-
nector. If a cable can
attach to multiple side
connectors, it is keyed
(or not keyed) so that it
will attach to all compati-
ble side connectors.
2
To connect a cable to a
side connector, locate
the appropriate side
connector.
3
Align the key pins on
the 22-Pin connector
with the key holes on
the case. Push the key
pins into the key holes.
Connecting a Cable to a Side Connector
