7 - 6
Controls
58.003
7.12 Bobbin thread control by stitch counting –926/07
● When the pre-set number of stitches is
reached, LED 1 flashes.
After the bobbin has been changed,
you must press the "PM" key on the
operating panel.
● For how to pre-set the number of stitches,
see Chapter 9.07 Pre-setting stitch
counting function for bobbin thread
monitoring.
7.11 Bobbin thread supply monitor -926/06
PFAFF 1525
● When the set thread-end length is reach-
ed, diode 1 flashes and the machine is
stopped.
PFAFF 1526
● When the set thread end-length is
reached, diode 1 (left bobbin) or 2
(right bobbin) flashes.
To finish sewing the seam, release the
pedal and press it forwards again.
Fig. 7 - 11
2
1
Fig. 7 - 12
1
