Spare Parts List
EN 32 LC4.3HE AA10.
10. Spare Parts List
Set Level
26HF5473/10
1099h 9322 221 01682 LC260WX2-SL01 (LPL)
1099
h 9322 234 13682 LC260WX2-SLB2
1114 3139 188 89031 Keyboard Assy [E]
1114 3139 188 89032 Keyboard Assy [E]
1114 3139 267 16931 Keyboard Assy [E]
1123 3139 267 18361 iBoard Assy [HC]
1124 3139 267 18141 Side I/O Assy [D]
1125 3139 267 18131 LED/IR Assy [J]
1174 3139 188 89051 Audio Amp. Assy [C]
1178 3139 188 67361 LCD Clock Assy [O]
1180 3139 267 18141 Side I/O Assy [D]
1182 3139 267 18361 iBoard Assy [HC]
1188
h 3122 137 23191 Power Supply Unit 26"
8002 3104 311 08061 Cable 2p3/120/Inlet
8105 3139 131 05771 Cable 04p/280
8193 2422 076 00585 Cable 1.5M
8400 3104 157 03961 Cable 3p/180/3p
8402 3139 131 04481 Cable 5p/280/5p
8403 3139 131 04501 Cable 4p/280/4p
8405 3139 131 06341 Cable 4p/680/4p
8406 3139 131 06351 Cable 24p/340/24p
8407 3139 131 06361 Cable 8p6/220/6p Bk
8520 3139 131 06081 Cable Inverter
8684 3104 157 03961 Cable 3p/180/3p
8684 3139 131 04421 Cable 3p/340/3p
8870 3139 110 27811 Cable 5p/80/5p Bk
8903 3104 311 09141 Cable 4p/560
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3104 311 10051 Cable 3p/100/3p Wh
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06 3139 131 06001 Cable 30p/140/30p
b
5213 2422 264 00536 Loudsp. 5W fullrange
eSoftware (see Philips Service Website)
0606
0611
0626
0632
32HF7473/10
1099h 9322 217 44682 LC320W01-A6K1 (LPL)
1099
h 9322 229 23682 LC320W01-SL01
1099
h 9322 230 03682 LC320W01-SL06
1114 3139 267 16931 Keyboard Assy [E]
1123 3139 267 18361 iBoard Assy [HC]
1174 3139 188 89051 Audio Amp. Assy [C]
1178 3139 188 67361 LCD Clock Assy [O]
1182 3139 267 18361 iBoard Assy [HC]
1188
h 3122 137 23171 Power Supply Unit 32"
8002 3104 311 08061 Cable 2p3/120/Inlet
8105 3139 131 05771 Cable 04p/280
8193 2422 076 00585 Cable 1.5M
8400 3139 110 27711 Cable 3p/560/3p Bk
8402 3139 131 06331 Cable 5p/340/5p
8403 3139 131 04501 Cable 4p/280/4p
8405 3139 131 04731 Cable 4p/1000/4p
8406 3139 131 06381 Cable 24p/220/24p
8407 3139 131 06361 Cable 8p6/220/6p Bk
8520 3139 131 05641 Cable 12p/820 280/12p
8520 3139 131 07611 Cable Inverter
8684 3104 157 03961 Cable 3p/180/3p
8684 3139 131 04421 Cable 3p/340/3p
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3139 110 27651 Cable 3p/100/3p
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06 3139 131 05471 Cable 30p/280/30p
b
5213 2422 264 00536 Loudsp. 5W fullrange
eSoftware (see Philips Service Website)
0606
0611
0626
0632
0635
Small Signal Board [B]
Various
1101 2422 025 18749 Connector 3p m
1102 3139 147 19801 Tuner UV1318S/A IH -3
1103 2422 025 17764 Connector 4P M
1104 2422 549 44372 SAW 38.9MHz K3953L
1106 2422 549 44369 SAW 38.9MHz K9656L
1107 2422 025 18749 Connector 3p m
1202 2422 543 01414 Xtal 24.576MHz
1440 2422 025 17931 Connector 5P m
1801 2422 543 01133 Xtal 14.32MHz 20pF
1F00 2422 033 00515 Socket DVI-I 29p f
1F01 2422 026 05703 Socket Cinch 1p f
1G01 4822 265 10703 Socket scart 21p
1G02 4822 265 10703 Socket scart 21p
1J02 2422 025 10772 Connector 12p m
1J03 2422 025 10768 Connector 3p m
1J04 2422 025 10769 Connector 9p m
1K00 2422 025 08149 Connector 6p m
1K01 2422 025 10772 Connector 12p m
1K02 2422 025 10768 Connector 3p m
1N05 2722 171 08825 Xtal 14.31818Mhz 15pF
1P01 2422 549 45325 Bead 67Ω at 100MHz
1P02 2422 549 45325 Bead 67Ω at 100MHz
1P03 2422 549 45325 Bead 67Ω at 100MHz
1P04 2422 549 45325 Bead 67Ω at 100MHz
1P05 2422 549 45325 Bead 67Ω at 100MHz
1P06 2422 025 18772 Connector 30p m
g
2101 4822 124 12095 100μF 20% 16V
2102 5322 126 11583 10nF 10% 50V 0603
2103 5322 126 11583 10nF 10% 50V 0603
2104 4822 122 33761 22pF 5% 50V
2105 4822 122 33761 22pF 5% 50V
2106 5322 126 11583 10nF 10% 50V 0603
2107 3198 024 44730 47nF 50V 0603
2109 5322 124 41945 22μF 20% 35V
2113 4822 124 12095 100μF 20% 16V
2203 4822 124 23002 10μF 16V
2206 2020 552 00183 2.2μF 10% 6.3V 0603
2207 2020 552 96718 220nF 10% 6.3V 0402
2208 4822 124 12084 1μF 20% 50V
2209 4822 124 23002 10μF 16V
2210 2020 552 96718 220nF 10% 6.3V 0402
2211 2020 552 96628 10nF 10% 16V 0402
2214 2020 552 96618 1nF 10% 50V 0402
2216 2020 552 96618 1nF 10% 50V 0402
2218 3198 035 71040 100nF 10% 16V 0402
2221 4822 124 12095 100μF 20% 16V
2223 2238 869 15101 100pF 5% 50V 0402
2225 2020 552 96618 1nF 10% 50V 0402
2226 3198 035 03320 3.3nF 5% 50V 0402
2227 2020 552 96618 1nF 10% 50V 0402
2228 3198 035 71040 100nF 10% 16V 0402
2230 3198 035 71040 100nF 10% 16V 0402
2231 2020 552 96718 220nF 10% 6.3V 0402
2232 3198 035 71040 100nF 10% 16V 0402
2233 4822 124 23002 10μF 16V
2234 2020 552 96718 220nF 10% 6.3V 0402
2235 2020 552 96718 220nF 10% 6.3V 0402
2236 4822 126 14076 220nF +80/-20% 25V
2237 2020 552 96718 220nF 10% 6.3V 0402
2238 2020 552 96718 220nF 10% 6.3V 0402
2239 3198 035 71040 100nF 10% 16V 0402
2240 2020 552 96718 220nF 10% 6.3V 0402
2241 2020 552 96718 220nF 10% 6.3V 0402
2242 3198 035 71040 100nF 10% 16V 0402
2243 4822 124 23002 10μF 16V
2244 3198 035 71040 100nF 10% 16V 0402
2245 3198 035 71040 100nF 10% 16V 0402
2246 3198 035 71040 100nF 10% 16V 0402
2250 2020 552 96618 1nF 10% 50V 0402
2251 2020 552 96656 10μF 20% 25V 1210
2252 3198 035 71040 100nF 10% 16V 0402
2253 3198 035 71040 100nF 10% 16V 0402
2254 3198 035 71040 100nF 10% 16V 0402
2255 3198 035 71040 100nF 10% 16V 0402
2256 4822 124 23002 10μF 16V
2257 3198 035 71040 100nF 10% 16V 0402
2258 2020 552 96637 10μF 10% 6.3V 0805
2259 3198 035 71040 100nF 10% 16V 0402
2260 2020 552 96637 10μF 10% 6.3V 0805
2262 4822 124 12082 10μF 20% 50V
2263 3198 035 26820 6.8nF 10% 16V 0402
2264 3198 017 44740 470nF 10V 0603
2265 3198 017 41050 1μF 10V 0603
2266 3198 035 71040 100nF 10% 16V 0402
2267 2020 552 96718 220nF 10% 6.3V 0402
2269 2022 031 00373 470μF 20% 16V
2270 3198 035 71040 100nF 10% 16V 0402
2271 4822 124 12095 100μF 20% 16V
2272 3198 035 71040 100nF 10% 16V 0402
2273 2020 552 96718 220nF 10% 6.3V 0402
2274 3198 017 31540 150nF 10V 0603
2277 3198 035 71040 100nF 10% 16V 0402
2280 2020 552 00027 4.7μF 2% 6.3V 0603
2281 2020 552 00027 4.7μF 2% 6.3V 0603
2285 3198 035 71040 100nF 10% 16V 0402
2286 3198 035 71040 100nF 10% 16V 0402
2290 2222 240 59872 4.7μF 5% 10V 0805
2291 3198 035 71040 100nF 10% 16V 0402
2449 3198 035 71040 100nF 10% 16V 0402
2603 2020 552 96834 1μ
F 20% 6.3V 0402
2604 3198 035 04710 470pF 50V 0402
2605 2020 552 96834 1μF 20% 6.3V 0402
2608 2020 552 96834 1μF 20% 6.3V 0402
2609 3198 035 04710 470pF 50V 0402
2610 2020 552 96834 1μF 20% 6.3V 0402
2611 4822 124 12095 100μF 20% 16V
2613 3198 017 41050 1μF 10V 0603
2614 3198 035 71040 100nF 10% 16V 0402
2615 2022 031 00373 470μF 20% 16V
2616 2020 552 00183 2.2μF 10% 6.3V 0603
2617 2020 552 00183 2.2μF 10% 6.3V 0603
2618 2022 031 00373 470μF 20% 16V
2619 2020 552 96738 47μF 6.3V
2701 2238 869 15101 100pF 5% 50V 0402
2704 4822 124 23002 10μF 16V
2716 2020 012 00028 470μF 20% 16V
2730 2020 552 96656 10μF 20% 25V 1210
2731 2022 031 00373 470μF 20% 16V
2733 3198 035 02210 220pF 5% 50V 0402
2734 2238 787 16641 22nF 10% 16V 0402
2735 3198 035 04710 470pF 50V 0402
2736 2022 031 00308 22μF 20% 35V
2737 2022 031 00373 470μF 20% 16V
2738 4822 124 80151 47μF 16V
2739 4822 124 80151 47μF 16V
2750 2020 552 00183 2.2μF 10% 6.3V 0603
2751 3198 035 71040 100nF 10% 16V 0402
2752 4822 124 80151 47μF 16V
2753 2022 031 00373 470μF 20% 16V
2755 3198 035 14720 4.7nF 5% 25V 0402
2756 3198 035 04710 470pF 50V 0402
2757 2022 031 00373 470μF 20% 16V
2758 2022 031 00373 470μF 20% 16V
2760 2020 552 96671 1μF 10% 25V
2800 2020 021 91557 100μF 20% 16V
2801 3198 035 71040 100nF 10% 16V 0402
2802 3198 035 71040 100nF 10% 16V 0402
2803 3198 035 71040 100nF 10% 16V 0402
2804 3198 035 71040 100nF 10% 16V 0402
2805 3198 035 71040 100nF 10% 16V 0402
2806 3198 035 71040 100nF 10% 16V 0402
2807 3198 035 71040 100nF 10% 16V 0402
2808 3198 035 71040 100nF 10% 16V 0402
2809 3198 035 71040 100nF 10% 16V 0402
2810 3198 035 71040 100nF 10% 16V 0402
2811 3198 035 71040 100nF 10% 16V 0402
2812 3198 035 71040 100nF 10% 16V 0402
2813 3198 035 71040 100nF 10% 16V 0402
2814 3198 035 71040 100nF 10% 16V 0402
2815 5322 124 41945 22μF 20% 35V
2816 3198 035 71040 100nF 10% 16V 0402
2817 3198 035 71040 100nF 10% 16V 0402
2818 3198 035 71040 100nF 10% 16V 0402
2819 3198 035 71040 100nF 10% 16V 0402
2820 3198 035 71040 100nF 10% 16V 0402
2821 3198 035 71040 100nF 10% 16V 0402
2822 3198 035 71040 100nF 10% 16V 0402
2823 4822 126 14519 22pF 5% 50V 0402
2824 4822 126 14519 22pF 5% 50V 0402
2900 3198 035 71040 100nF 10% 16V 0402
