Mechanical Instructions
EN 4 LC4.3HE AA4.
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Position
4.3 Assy/Panel Removal
4.4 Set Re-assembly
Notes:
• Only information that is related to the iTV module, is
published in this manual. For other information, see the
relevant chassis manual (order code on front page).
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
• Follow the disassembling instructions in described order.
4.1 Cable Dressing
Figure 4-1 Cable dressing (26-inch model)
Figure 4-2 Cable dressing (32-inch model)
F_15800_002.eps
281105
F_15800_001.eps
281105
