Service Modes, Error Codes, and Fault Finding
EN 7LC4.3HE AA 5.
5. Service Modes, Error Codes, and Fault Finding
Index of this chapter:
5.1 Hotel Mode, Service Modes
5.1 Hotel Mode, Service Modes
5.2 Error Codes
5.3 i-Board and LCD Clock
5.1 Hotel Mode, Service Modes
5.1.1 Hotel Mode
Before the service modes can be activated, the set needs to
beswitched into normal consumer mode (MTV-Mode) first. Use
an iTV setup remote control (type: RC2753/01, 12nc: 3139 228
88782) to key in the code ‘024995’ directly followed by the
MENU button. The text messages “TV Is Now In MTV Mode”
and “Please Do A Cold Start !” appears on the screen.
Disconnect the set for a few seconds from the mains supply,
reconnect the set to the mains supply again. The set is now in
the normal consumer mode (MTV-Mode).
After repair, place the set into hotel mode (iTV-Mode) again.
Key-in the same code on the remote control as described
above. The text message “TV Is Now In ITV Mode” appears.
A cold start must be performed as described above. The set is
now in the hotel mode (iTV-Mode) again.
5.1.2 Service Modes
Only when the set is in normal consumer mode (MTV Mode),
all service modes can be accessed. Refer to the main chassis
manual for further explanation of the service modes.
5.2 Error Codes
The error code buffer contains all errors detected since the last
time the buffer was erased. The buffer is written from left to
right. When an error occurs that is not yet in the error code
buffer, it is displayed at the left side and all other errors shift one
position to the right.
Table 5-1 Error code overview
Error Error Description Check Item Diagram
0 No Error
1 Mis-match of TV (Hercules) SW and
Scaler SW
Software
versions
N.A.
2 +12V from PSU error PSU A
3 Plasma I
2
C error (only for plasma sets) N.A. N.A.
4I
2
C error while communicating with the
Genesis Scaler
7801 B7 + B8
5 +5V protection 7752 B6
6 General I
2
C error; communication
between ADC, analogue tuner, and/or
Columbus I
2
C failed
1102, 7L01,
7M00
B1 + B18 +
B19
7I
2
C error while communicating with
ADC
7L01 B18
8I
2
C error while communicating with the
Scaler EEPROM
7C01 B11
9I
2
C error while communicating with the
Hercules EEPROM (NVM for TV).
Remark: when the Hercules EEPROM
is defective, the Hercules should
operate with its default values.
7217 B2
10 I
2
C error while communicating with the
PLL tuner
1102 B1
11 I
2
C error while communicating with the
3D combfilter IC-7M00 (Columbus)
7M00 B19
12 I
2
C error while communicating with i-
Board uP (only iTV sets)
N.A. N.A.
13 I
2
C error while communicating with the
HDMI decoder IC-7D03 (only for
NAFTA and AP)
N.A. N.A.
14 Read-write error with the Scaler
SDRAM
7B01 B10
15 I
2
C error while communicating with the
OTC
--
16 I
2
C error while communicating with
EPLD or Pacific III
7N02 B20 + B21
17 I
2
C error while communicating with the
Digital Module (only for digital sets)
N.A. N.A.
18 IBO hardware error (only for digital
sets)
N.A. N.A.
