Make one of the following connections, depending on the capabilities of your existing device.
OUT
S-VIDEO
S-VIDEO IN
TV
this unit
Note for HDMI connection
• A simple 1-cable connection with a device having an HDMI (high-definition multimedia interface) connector
allows digital transfer of the digital images of DVD-video and other devices.
When connecting with an HDMI cable, the audio signal will be output as the digital audio signal simultaneously,
so you do not need the analog audio connection described above.
Note
• Connect this unit directly to the TV. If the RCA audio/video cables are connected to a VCR, pictures may be
distorted due to the copy protection system.
To set progressive scan mode, refer to page 110
• This unit is compatible with the progressive scan system. The feature provides you with the higher quality images than the
traditional output system does. To utilize this feature, you must set “Progressive Scan” to “ON”.
CONNECTION TO A TV
VIDEO
OUT
R
L
AV OUT
VIDEO
IN
Supplied cables used in this connection are as follows:
• RCA audio cable (L/R) x 1
• RCA video cable x 1
Please purchase the rest of the necessary cables at your local store.
and or or
HDMI OUT
HDMI IN
HDMI
cable
analog audio
RCA
audio cable
RCA
video
cable
S-video
cable
component
video cable
Method 3
better picture
COMPONENT
VIDEO OUT
Method 2
good picture
S-VIDEO OUT
Method 1
standard picture
VIDEO OUTAV OUT
Method 4
best picture
HDMI OUT
or
