Philips HTL4110B User Manual

11EN
Note
• This product may not be compatible with certain types
of USB storage device.
• If you use a USB extension cable, USB HUB, or USB
multi-reader, the USB storage device may not be
recognized.
• Digital camera PTP protocols are not supported.
• Do not remove the USB storage device while it is
being read.
• DRM-protectedmusicles(MP3,WMA)arenot
supported.
• Support a USB port: 5V , 1A.
Auto standby
When playing media from a connected device,
the SoundStage automatically switches to
standby if:
• no button is pressed for 30 minutes, or
• no audio/video play from a connected
device (except USB) for 30 minutes.
Apply factory settings
You can reset this product to the default
settings programmed at the factory.
1 In standby mode, press and hold button
on the main unit for at least 5 seconds
until the product powers on.
6 Update software
To get the best features and support, update
your product with the latest software.
Check software version
1 In any source mode, press .
2 Press AUX/AUDIO IN twice on the
remote control.
» The software version number is
displayed.
Update software via USB
1 Check the latest software version on
www.philips.com/support.
• Search for your model and click on
"Software and drivers".
2 Download the software into a USB storage
device.
a Unzip the download if zipped, and
make sure that the unzipped folder is
named "HTL4110B_12.BIN".
b Put the "HTL4110B_12.BIN" folder in
the root directory.
3 Connect the USB storage device to the
USB connector of this product.
4 Press USB on the remote control, within 5
seconds press twice, and VOL + once,
then hold down .
» Ifanupgradeleisdetected,[UPG]
willbefastashed.
» Ifanupgradeleisnotdetected,
[ERROR]willbeslowlyashed.
5 Press to start the update.
» [UPG]isdisplayed.

Philips HTL4110B Specifications

General

Package depth	372 mm
Package width	800 mm
Package height	142 mm
Package weight	8600 g
Impedance	4 Ω
Number of tweeter drivers	1
Soundbar speaker RMS power	40 W
Tweeter diameter (imperial)	1 \
Total Harmonic Distortion (THD)	10 %
Quantity outer carton	1 pc(s)
Width (cm) outer carton	38.8 cm
Height (cm) outer carton	17.1 cm
Length (cm) outer carton	82 cm
Docking connector type	-
Apple docking compatibility	Not supported
Master (outer) case weight	9510 g
Audio decoders	Dolby Digital
RMS rated power	80 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
Recommended usage	Universal
Audio formats supported	MP3, WMA
Consumer Electronics Control (CEC)	EasyLink
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless

Weight and Dimensions

Depth	325 mm
Width	701 mm
Height	68 mm
Soundbar weight	6500 g
