Functiondescription
OperatingManualPNOZms1p
20967EN11
12
4 Functiondescription
4.1 Integratedprotectionmechanisms
Therelayconformstothefollowingsafetycriteria:
} Thecircuitisredundantwithbuiltinselfmonitoring.
} Thesafetyfunctionremainseffectiveinthecaseofacomponentfailure.
4.2 Operation
Thespeedmonitorcanindependentlymonitortwoaxesforstandstill,speedanddirection
ofrotation.Thespeedmonitorsignalsthestatusofthemonitoredvaluestothebaseunit.
Dependingonthesafetycircuitloaded,thevaluescanbetransferredfromthebaseunit,
e.g.toarelayoutputonthesafetysystem.Incrementalencodersand/orproximitydetectors
canbeusedtorecordthevalues.
TheconfigurationofthespeedmonitorisdescribedindetailinthePNOZmultiConfigur
ator'sonlinehelp.
4.3 Blockdiagram
RJ45 RJ45
4.4 Inputdevicetypes
4.4.1 Proximityswitch
4.4.1.1 Requirementsoftheproximityswitches
} Only"pnp"typeproximityswitchesmaybeused(N/Ocontact,switchingtopositive).
} Theproximityswitchesrequirea24VDCsupply.
} Theproximityswitchesmustbefittedsothatatleastoneisalwaysactivated(carriesa
highsignal).
