Installation
OperatingManualPNOZms1p
20967EN11
16
5.2 Connectingthebaseunitandexpansionmodules
Connectthebaseunitandtheexpansionmodulesasdescribedintheoperatingmanuals
forthebasemodules.
} Theterminatormustbefittedtothelastexpansionmodule
} InstalltheexpansionmoduleinthepositionconfiguredinthePNOZmultiConfigurator.
Youcaninstallamaximumof4speedmonitorstotherightofthebaseunit.
Base unit
Expansion module 1 Expansion module 8
774639: Jumper 779110: Terminator
Speed monitor
max. 4 Speed monitors
5.3 Dimensions
94 (3.70")
45
(1.77")
121 (4.76")
