Pilz PNOZ ms1p User Manual

Installation
OperatingManualPNOZms1p
20967EN11
15
5 Installation
5.1 Generalinstallationguidelines
} Thecontrolsystemshouldbeinstalledinacontrolcabinetwithaprotectiontypeofat
leastIP54.Fitthecontrolsystemtoahorizontalmountingrail.Theventingslotsmust
faceupwardanddownward.Othermountingpositionscoulddestroythecontrolsystem.
} Usethenotchesontherearoftheunittoattachittoamountingrail.Connectthecon
trolsystemtothemountingrailinanuprightposition,sothattheearthingspringsonthe
controlsystemarepressedontothemountingrail.
} TheambienttemperatureofthePNOZmultiunitsinthecontrolcabinetmustnotexceed
thefigurestatedinthetechnicaldetails,otherwiseairconditioningwillberequired.
} TocomplywithEMCrequirements,themountingrailmusthavealowimpedancecon
nectiontothecontrolcabinethousing.
NOTICE
Damageduetoelectrostaticdischarge!
Electrostaticdischargecandamagecomponents.Ensureagainstdischarge
beforetouchingtheproduct,e.g.bytouchinganearthed,conductivesur
faceorbywearinganearthedarmband.

Pilz PNOZ ms1p Specifications

General

Brand	Pilz
Model	PNOZ ms1p
Category	Control Systems
Language	English
