Commissioning
OperatingManualPNOZms1p
20967EN11
21
Incremental
encoder
A
/A
B
/B
Z
o
Z
o
X12
X22
Speed monitor
Drive
Adapter
5 V
0 V
5 V DC
0 V
1 8
Fig.:Connectionviaadapteranddrive
6.5 Connectionofproximityswitchesandincrementalencoder
6.5.1 Proximityswitchandincrementalencoderonvariousaxes
Axis1:
proximityswitchonI10,I11
or
incrementalencoderonX12
Axle2:
proximityswitchonI10,I21
or
incrementalencoderonX22
Fig.:Proximityswitchandincrementalencoderonvariousaxes
