Commissioning
OperatingManualPNOZms1p
20967EN11
25
6.6.3 Connectionofanincrementalencoderandproximityswitchonanaxis
Description
} 1proximityswitch,pnpswitching
} 1incrementalencoder
} Incrementalencoderandproximityswitchononeaxis
Speed monitor
Incremental encoder
PNOZ msi15p
Drive
Fig.:Connectionofanincrementalencoderandproximityswitch,pnpswitching,onanaxis
