24
A-209R, A-209
Mark No. Description Part No.
Mark No. Description Part No.
Mark No. Description Part No.
Mark No. Description Part No.
5. PCB PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 10
1
→ 561 ........................................................ RD1/4PU
5
6
1
J
47k Ω→47 × 10
3
→ 473 ........................................................ RD1/4PU
4
7
3
J
0.5 Ω→R50 ..................................................................................... RN2H
R
5
0
K
1 Ω→1R0 ..................................................................................... RS1P
1
R
0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 10
1
→ 5621 ...................................................... RN1/4PC
5
6
2
1
F
LIST OF WHOLE PCB ASSEMBLIES
VOLUME ASSY
(1) CONTRAST TABLE
AWX7118 and AWX7112 are constructed the same except
for the following :
(2) PARTS LIST FOR AWX7118
SEMICONDUCTORS
Q513,Q514 2SK246
Q501-Q510 2SK303
Q511 DTC124EK
D505,D506,D509,D510 1SS352
D501-D504,D507,D508 1SS355
CAPACITORS
C501,C502 CCSQCH271J50
C513,C514 CEAT100M50
C516 CEAT330M25
C503,C504 CFTYA473J50
C515 CKCYF103Z50
C511 CKSQYF473Z50
RESISTORS
R530 RS1/10S100J
VR501 ACX7038
Other Resistors RS1/10S J
A
OTHERS
CN501 16P SOCKET KP200TA16L
CN502 CONNECTOR 7P KPE7
PCB BINDER VEF1040
HEADPHONE ASSY
CAPACITORS
C551,C552 CKSQYB392K50
OTHERS
3P CABLE HOLDER 51063-0305
J552 CORD WITH PLUG DE005WE0
JA501 HEADPHONE JACK RKN1002
J551 JUMPER WIRE D15A03-150-2651
AC PRIMARY ASSY
(1) CONTRAST TABLE
AWX7113 and AWX7670 are constructed the same except
for the following :
(2) PARTS LIST FOR AWX7113
SWITCH
S801 ASG1035
B
C
Mark Symbol and Description
Part No.
Remarks
AWX7113 AWX7670
H3-H6 FUSE CLIP Not used AKR7001
NSP J806 Not used DB616EB0
Mark Symbol and Description
Part No.
Remarks
AWX7118 AWX7112
C511 CKSQYF473Z50 Not used
VR501 ACX7038 ACS7035
Part No.
Mark Symbol and Description A-209R A-209R A-209 A-209 Remarks
/MYXJ /MVXJ /MLXJ /SBDXJ
NSP AF COMPLEX ASSY AWM7357 AWM7357 AWM7355 AWM7511
VOLUME ASSY AWX7118 AWX7118 AWX7112 AWX7112
NSP HEADPHONE ASSY AWX7114 AWX7114 AWX7114 AWX7114
AC PRIMARY ASSY AWX7113 AWX7113 AWX7113 AWX7670
AF ASSY AWX7117 AWX7117 AWX7116 AWX7116
NSP CONTROL ASSY AWG7013 AWG7013 AWG7012 AWG7012
FRONT L ASSY AWX7123 AWX7123 AWX7122 AWX7122
FRONT R ASSY AWX7124 AWX7124 AWX7121 AWX7121
OPT ASSY AWX7125 AWX7125 Not used Not used
To Next Page
