Pioneer A-209R Service Manual

A-209R, A-209
28
7. GENERAL INFORMATION
2
1
1
1
1
1
5
1
5
×2
×2
3
4
×2
5
×5
×3
×2
8
7
7
7
9
Screw for Rear Panel
Rear Panel
Rear Panel
Front Panel
Diagnose the
AF Assy.
Chassis
Chassis
6 6 6
Cutting Pliers
PCB Support
×3
Unhook lead wires.
1 3
2
For
Service
10
13
11
12
∗ : Be careful not to injure
the Front Panel.
7.1 DISASSEMBLY

Pioneer A-209R Specifications

General

Power Output	30W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Total Harmonic Distortion	0.08% (20Hz - 20kHz, 15W, 8 ohms)
Signal-to-Noise Ratio	76dB (MM), 100dB (Line)
Input Sensitivity	2.5mV (MM), 150mV (Line)
Dimensions	420 x 114 x 307 mm
Weight	6.7 kg
Signal to noise ratio	100dB
Frequency Response	5Hz to 100kHz
