Pioneer DVH-760AV/XEUW5 User Manual

DVH-760AV/XEUW5
11
5 678
56
7
8
C
D
F
A
B
E
3.3 JIGS LIST
3.4 CLEANING
3.5 FACTORY SETTINGS
- Jigs List
Name
21P FFC
Acetate Tape
Jig No.
GGD1627
GYH1026
Remarks
MB Assy (Mother) - SB Assy (DVD Decode)
Disassembly
Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools:
Portions to be cleaned Cleaning tools
DVD pickup lenses Cleaning liquid : GEM1004
Cleaning paper : GED-008
- When the Repair is Complete
When the repair is complete, make the DVD mechanism ready for transportation
implementing the following procedures:
1. Attach the two Transportation Screws.
Now you can transport it.(See the figure below)
Transportation Screws
121045000198-FY
