7. DISASSEMBLY
Deck
1
1
2
3
Fig.1
Fig.2
Removing the Top Cover and the Bottom Cover (Fig.1)
Removing the Deck (Fig.2)
Remove the screw and then remove the
Bottom Cover.
Remove the screw and then remove the
To p Cover.
Bottom Cover
To p Cover
2
2
2
1
1
1
2
Remove the two screws.
Remove the two screws.
Disconnect the two connectors and then
remove the Deck.
3
3
