Pioneer PD-117 User Manual

8
En
ABOUT THESE OPERATING INSTRUCTIONS
The contents found in these Operating Instructions are based on
the PD-217 models, but they are also applicable to the PD-117
model.
AC power cord connection and functions
Some functions cannot be carried out depending on the connection
of the AC power cord.
When the AC power
cord is connected to
the switched outlet
of an amplifier or
audio timer.
Yes
No
No
When the AC power
cord is connected to
the unswitched outlet
of an amplifier or wall
outlet.
No
Yes
Yes
Function
Timer playback
Program memory
Output level memory
(PD-217 only)
CONTENTS
ABOUT THESE OPERATING INSTRUCTIONS ............................... 8
CAUTIONS REGARDING HANDLING ............................................ 9
CONNECTIONS ........................................................................... 12
CONFIRM SUPPLIED ACCESSORIES ......................................... 16
PUT BATTERIES INTO THE REMOTE
CONTROL UNIT (PD-217 ONLY) ................................................. 16
NAMES AND FUNCTIONS OF PARTS ........................................ 18
BASIC OPERATION ..................................................................... 20
VARIOUS OPERATIONS .............................................................. 22
TO PLAY ONLY DESIRED TRACKS ............................................. 26
CONVENIENT OPERATION FOR RECORDING ........................... 30
SPECIFICATIONS ......................................................................... 32
TROUBLESHOOTING .................................................................. 34

Pioneer PD-117 Specifications

Power

power requirements	220 - 240 V, 50/60 Hz
power consumption	12 W
operating temperature	+5˚C - +35˚C

Audio Performance

frequency response	2 Hz - 20 kHz
signal to noise ratio	98 dB or more
dynamic range	96 dB or more
harmonic distortion	0.003% or less
output voltage	2.0 V

Weight and Dimensions

weight	3.1 kg
width	420 mm
height	101 mm
depth	263 mm
