5. PCB PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 10
1
→ 561 ........................................................ RD1/4PU
5
6
1
J
47k Ω→47 × 10
3
→ 473 ........................................................ RD1/4PU
4
7
3
J
0.5 Ω→R50 ..................................................................................... RN2H
R
5
0
K
1 Ω→1R0 ..................................................................................... RS1P
1
R
0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 10
1
→ 5621 ...................................................... RN1/4PC
5
6
2
1
F
LIST OF ASSEMBLIES
CIRCUIT PARTS ASSY AZW7259
NSP TUNER PCB • • • ••
NSP MAIN PCB • • • ••
NSP PHONE PCB • • • ••
NSP AC O/P PCB • • • ••
NSP AC I/P PCB • • • ••
NSP PW SW PCB • • • ••
NSP DISPLAY PCB • • • ••
CIRCUIT PARTS ASSY
SEMICONDUCTORS
IC201 00201041-040
IC102 00201838-040
IC702 00202879-040
IC202,IC208 00206458-040
IC203 00262419-010
IC701 00272358-040
IC703 06104421-000
IC101 LA1186N
IC204,IC205 STK407-070
Q711-Q713 00300144-142
Q104,Q402,Q701,Q702 00300536-046
Q103,Q401,Q804 00300608-045
Q101 00300715-041
Q801 00301134-049
Q803 00301667-048
Q102,Q105-Q107 00302999-044
Q201-Q204 00303576-040
Q802 00304485-049
Q205-Q213 00310536-046
Q714 DTA114ES
Q703 DTA143ES
Q704 DTC143ES
D802 00400004-300
D803 00400040-301
D101,D102 00400321-500
D209,D211,D212 00494001-300
D7010,D7020,D7030 01912000-034
D1,D103,D104,D201-D208 1SS133
D210,D701-D704,D714,D801 1SS133
D8050,D8060 MTZJ10C
D8010,D8020 MTZJ13B
D8070 MTZJ4.7B
D8040 MTZJ6.8B
D105,D106 SVC201SPA
SWITCHES AND RELAYS
S1,S10-S19,S2 02031100-163
S20-S23,S26,S27,S29 02031100-163
S3,S30-S32,S4,S5 02031100-163
S1001 02041100-004
RY1,RY2 06500224-002
COILS
L202-L204 CHOKE COIL 01500030-006
L701 CHOKE COIL (1MHz) 01500102-001
L101 BIAS TRAP COIL 01500393-001
L102 FM COIL 01705037-350
L104 FM COIL 01706036-350
L201 CHOKE COIL 01710205-100
F103 CERAMIC FILTER 02800450-000
F101,F102 CERAMIC FILTER 02810700-009
F104 CERAMIC DTS. 02810700-025
F1010 BPF GFWB3 02876108-002
TRANSFORMERS
T102 OSC 7MM N00360 01620360-023
T101 AM ANT OH 01621032-104
T103 FM IFT OH-827539 01627539-032
T104 AM IFT OH-827539 01627580-041
CAPACITORS
C235-C242,C715-C717 00610101-250
C121-C124,C127,C130,C131 00610102-550
C136,C165,C711 00610102-550
C818 00610103-301
C813,C819-C823 00610103-503
C110,C3 00610103-550
C133,C226,C233,C281,C282 00610104-550
C378,C704,C709,C710,C712 00610104-550
C714 00610104-550
C111 00610201-250
C101,C103,C105,C120,C126 00610203-550
C106,C225,C234 00610221-250
C713 00610224-550
C250,C251,C260,C261 00610471-250
C810-C812 00610472-550
