Pioneer VSX 108 - AV Receiver User Manual

33
VSX-108
04991693-001 (9-MT-169GK) (DISPLAY PCB : V1)
• FL TUBE
7.1.2 DISPLAY
•
Grid Assignment
•
Pin Connection
1 35
1G
Dp1
a
d
hk
r
n
fb
ec
j
mg
Dp2
2G 3G 4G 5G 6G 7G 8G 9G
p
Pin No.
123456789101112131415161718
Connection
F1 F1 NP 1G 2G 3G 4G 5G 6G 7G 8G 9G NC NC NC NC NC P15
Pin No.
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35
Connection
P14 P13 P12 P11 P10 P9 P8 P7 P6 P5 P4 P3 P2 P1 NP F2 F2
Note 1) F1, F2 : Filament
2) NP : No Pin
3) NC : No connection
4) DL : Datum Line
5) 1G - 9G : Grid
