OTHER
OTHER
31
<ARB7146>
5
OTHER
MAINTENANCE OF EXTERNAL SURFACES
¶ Use a polishing cloth or dry cloth to wipe off dust
and dirt.
¶ When the surfaces are very dirty, wipe with a soft
cloth dipped in some neutral cleanser diluted five or
six times with water, and wrung out well, and then
wipe again with a dry cloth. Do not use furniture wax
or cleaners.
¶ Never use thinners, benzene, insecticide sprays or
other chemicals on or near this unit, since these will
corrode surfaces.
SPECIFICATIONS
Amplifier Section
Continuous rated power output of 65
watts* per channel, min., at 8 ohms, from
40 Hz to 20,000 Hz with no more than 0.09
%** total harmonic distortion (front).
Continuous Power Output
(DIN, 1 kHz, T.H.D. 1 %, 8 Ω)
STEREO Front ............................... 70 W + 70 W
SURROUND Front ............................... 50 W + 50 W
Center .......................................... 50 W
Rear .............................................. 50 W
Input (Sensitivity/Impedance)
PHONO MM ................................................ 2.8 mV/47 kΩ
CD, VCR/TAPE 1, TAPE 2, DVD/LD ............ 200 mV/47 kΩ
Phono Overload Level (T.H.D. 0.1 %, 1kHz)
PHONO MM ............................................................ 90 mV
Frequency Response*
PHONO MM ......................... 20 Hz to 20,000 Hz ± 0.5 dB
CD, VCR/TAPE 1, TAPE 2, DVD/LD
.................................................. 5 Hz to 100,000 Hz
+0
–3
dB
Output (Level/Impedance)
VCR/TAPE 1 REC, TAPE 2 REC .................... 200 mV/1 kΩ
Tone Control
BASS ........................................................ ± 8 dB (150 Hz)
TREBLE .................................................... ± 8 dB (10 kHz)
LOUDNESS ........................ +8 dB/+6 dB (100 Hz/10 kHz)
Signal-to-Noise Ratio [DIN (Rated power output/50 mW)]*
PHONO MM .................................................. 68 dB/61 dB
CD, VCR/TAPE 1, TAPE 2, DVD/LD ............... 86 dB/63 dB
* Direct: ON
** Measured by Audio Spectrum Analyzer.
VIDEO Section
Input (Sensitivity/Impedance)
VCR/TAPE 1, DVD/LD ..................................... 1 Vp-p/75 Ω
Output (Level/Impedance)
VCR/TAPE 1 REC, MONITOR TV ................... 1 Vp-p/75 Ω
Frequency Response
VCR/TAPE 1, DVD/LD → MONITOR
.......................................................... 5 Hz to 7 MHz
+0
–3
dB
Signal-to-Noise Ratio ................................................ 55 dB
Cross Talk ................................................................... 55 dB
FM Tuner Section
Frequency Range............................. 87.5 MHz to 108 MHz
Usable Sensitivity....... Mono: 15.2 dBf, IHF (1.6 µV/75 Ω)
50 dB Quieting Sensitivity ........................Mono: 20.2 dBf
Stereo: 41.2 dBf
Signal-to-Noise Ratio ................. Mono: 76 dB (at 85 dBf)
Stereo: 72 dB (at 85 dBf)
Distortion ........................................... Stereo: 0.6 % (1kHz)
Alternate Channel Selectivity .................. 70 dB (400 kHz)
Stereo Separation ........................................ 40 dB (1 kHz)
Frequency Response ................... 30 Hz to 15 kHz (± 1) dB
Antenna Input ......................................... 75 Ω unbalanced
Sensitivity (DIN)........................ Mono: 1.1 µV (S/N 26 dB)
Stereo: 50 µV (S/N 46 dB)
Signal-to-Noise Ratio (DIN) .......................... Mono: 62 dB
Stereo: 58 dB
AM Tuner Section
Frequency Range.............................. 531 kHz to 1,602 kHz
Sensitivity (IHF, Loop antenna) ......................... 350 µV/m
Selectivity................................................................... 30 dB
Signal-to-Noise Ratio ................................................ 50 dB
Antenna ........................................................ Loop antenna
Miscellaneous
Power Requirements........................... AC 240 V, 50/60 Hz
Power Consumption ................................................ 390 W
Dimensions ..................... 420 (W) × 143 (H) × 334 (D) mm
Weight (without package) ........................................ 6.6 kg
Furnished Parts
FM Antenna ...................................................................... 1
AM Loop Antenna ............................................................ 1
Dry Cell Batteries [size “AA” (IEC R6P)] ......................... 2
Remote Control Unit ........................................................ 1
Operating Instructions ..................................................... 1
Warranty card ................................................................... 1
NOTE:
Specifications and the design are subject to possible
modifications without notice, due to improvements.
