1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
CONTRAST TABLE
VSX-D939TX/HL, LB and VSX-37TX/KU/CA are constructed the same except for the following :
Part No.
Ref. No. Mark Symbol and Description VSX-37TX VSX-D939TX VSX-D939TX Remarks
/KU/CA /HL /LB
ASSEMBLIES
NSP MAIN ASSY AWK7641 AWK7647 AWK7646
P5- 5 MAIN CONTROL ASSY AWX7706 AWX7712 AWX7711
P5-12 VIDEO ASSY AWX7394 AWX7677 AWX7677
NSP COMPLEX ASSY AWK7522 AWK7529 AWK7543
P5- 2 EXTERNAL IN ASSY AWX7398 AWX7413 AWX7413
P5- 3 A- PINJACK ASSY AWX7397 AWX7412 AWX7412
P5- 4 CONNECTION ASSY AWX7313 AWX7347 AWX7347
P5- 9 REGULATOR ASSY AWX7310 AWX7832 AWX7832
P5-10 TRANS 1 ASSY AWX7316 AWX7316 Not used
P5-10 TRANS 1/LB ASSY Not used Not used AWX7447
P5-11 TRANS 2-2 ASSY AWX7366 AWX7518 AWX7518
P5-15 PRIMARY ASSY AWX7311 AWX7345 AWX7429
NSP FRONT/VAMP ASSY AWK7656 AWK7661 AWK7661
P5-14 VOLUME ASSY AWX7367 Not used Not used
P9- 2 DISPLAY ASSY AWX7698 AWX7703 AWX7703
P9- 3 ROTARY ENCODER ASSY AWX7328 AWX7726 AWX7726
P- SW ASSY Not used AWX7330 AWX7330 No. 1
NSP POWER/CURRENT ASSY AWK7651 AWK7655 AWK7654
P5- 6 TRANS 2-1 ASSY AWX7694 AWX7696 AWX7696
P5- 8 SP/PS ASSY AWX7688 AWX7693 AWX7692
PACKING SECTION
P3- 2 FM Wire Antenna ADH7007 ADH7010 ADH7011
P3- 3 Operating Instructions (English) ARB7231 ARB7235 ARB7235
P3- 3 Operating Instructions (Chinese) Not used ARC7321 ARC7321
P3- 4 Remote Control Unit AXD7257 AXD7279 AXD7279
P3- 9 Packing Case AHD7881 AHD7889 AHD7889
P3-12 NSP Warranty Card ARY1026 Not used Not used
EXTERIOR SECTION
P5-20 AC Power Cord ADG7028 VDG1063 ADG7023
P5-21 Power Transformer (T1) ATS7252 ATS7253 Not used
P5-21 Power Transformer (T1) (AC110V) Not used Not used ATS7255
P5-22 FM/AM TUNER Unit AXX7046 AXX7048 AXX7047
P5-23
Fuse (FU1 : T4A) VEK1029 AEK-514 Not used
P5-23
Fuse (FU1 : 10A) VEK1029 Not used DEK1045
P5-24 Fuse (FU4 : T2A) REK1079 AEK-511 AEK-511
P5-25 Fuse (FU5 : T2A) REK1079 AEK-511 AEK-511
