VSX-D939TX
5
AWX7413 and AWX7398 are constructed the same except for the following :
EXTERNAL IN ASSY
F
A
Mark Symbol and Description
Part No.
Remarks
AWX7398 AWX7413
C1101- C1106 Not used CCCSL271J50
AWX7347 and AWX7313 are constructed the same except for the following :
CONNECTION ASSY
F
C
Mark Symbol and Description
Part No.
Remarks
AWX7313 AWX7347
C1301- C1306 Not used CCCSL680J50
C1353, C1354 Not used CCCSL181J50
C1355, C1356 Not used CKCYB331K50
C1365, C1366 CEAT101M16 CEAT101M25
L1351– L1354 Not used LAU181J
R1353, R1354 RD1/4PU331J RD1/4PU122J
MAIN CONTROL ASSY
F
D
AWX7712, AWX7711 and AWX7706 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
AWX7706 AWX7712 AWX7711
IC102 BU4052BCF Not used Not used
IC109 NJM4558MD Not used Not used
IC110 M62429FP Not used Not used
IC115 Not used NJM4558LD Not used
IC901 PD5589A PD5596A PD5596A
Q113, Q114 2SC2878 Not used Not used
D201, D202 UDZS5.1B Not used Not used
D251, D252 Not used 1SS355 Not used
D253 Not used UDZS5.1B Not used
C101- C106, C183- C188 Not used CCSQCH221J50 CCSQCH221J50
C113, C114 Not used CCSQCH331J50 CCSQCH331J50
C131, C132, C253, C254 Not used CKSQYB103K50 Not used
C141, C142, C145- C150 CEAT100M50 Not used Not used
C143, C144 CKSQYB103K50 Not used Not used
C252 Not used CEAT470M16 Not used
C155, C156, C165, C166 Not used CCSQCH101J50 CCSQCH101J50
C175, C176 Not used CCSQCH101J50 CCSQCH101J50
C960, C961 CCSQCH101J50 Not used Not used
R109 RD1/2VM391J Not used Not used
R110 RS1/10S472J Not used Not used
R129, R130 RS1/10S104J Not used Not used
R135, R136, R923, R926, R928 RS1/10S103J Not used Not used
R131, R132 RS1/10S471J Not used Not used
R133, R134, R141- R144 RS1/10S102J Not used Not used
R934- R936, R986, R987 RS1/10S102J Not used Not used
R207- R211, R252, R253 Not used RS1/10S104J Not used
R145, R146 RS1/10S473J Not used Not used
R254 Not used RS1/10S102J Not used
R251 Not used RS1/10S474J Not used
R255 Not used RS1/10S393J Not used
R325- R330, R333, R334 RS1/10S0R0J Not used Not used
R370, R996 Not used RS1/10S0R0J Not used
R924, R925, R927 Not used RS1/10S103J Not used
R923, R926 Not used Not used RS1/10S103J
JA931 VKB1060 Not used Not used
To Next Page
