VSX-D939TX
7
AWX7703 and AWX7698 are constructed the same except for the following :
DISPLAY ASSY
F
S
Mark Symbol and Description
Part No.
Remarks
AWX7698 AWX7703
IC7051 TC7W53FU Not used
IC7071 M66311FP Not used
Q7002, Q7054 DTC124EK Not used
Q7053 FMA1A Not used
D7002 SLR-343VR Not used
D7054- D7057 1SS355 Not used
D7071- D7079 SLR-343VR Not used
S7019, S7020 VSG1009 Not used
C7011, C7073, C7074 CKSQYB102K50 Not used
C7053 CKSQYB153K50 Not used
C7071 CEAL101M6R3 Not used
C7072 CKSQYB473K50 Not used
R7038, R7071- R7079 RS1/10S271J Not used
R7056 RS1/10S223J Not used
R7057, S7061 RS1/10S103J Not used
R7058 RS1/10S392J Not used
R7062 RS1/10S0R0J Not used
R7080- R7083 RS1/10S102J Not used
R7092 RS1/10S473J Not used
0505 VEF1040 Not used
CN7003 52045-0845 Not used
AWX7518 and AWX7366 are constructed the same except for the following :
TRANS 2-2 ASSY
F
O
Mark Symbol and Description
Part No.
Remarks
AWX7366 AWX7518
C5501 Not used CEANPR47M50
C5502 Not used ACH1237 (1µF/100V)
R5501 Not used RFA1/4PS100J
R5502 Not used RD1/4PU104J
AWX7726 and AWX7328 are constructed the same except for the following :
ROTARY ENCODER ASSY
F
T
Mark Symbol and Description
Part No.
Remarks
AWX7328 AWX7726
C7103, C7104 Not used CKSQYB103K50
R7103, C7104 Not used RS1/10S103J
S7101 Not used ASX7004
AWX7832 and AWX7310 are constructed the same except for the following :
REGULATOR ASSY
F
M
Mark Symbol and Description
Part No.
Remarks
AWX7310 AWX7832
IC5001, C5002 NJM78M15FA NJM7815FA
R5004, R5005 Not used RS2LMF2R7J
