VSX-D939TX
4
CONTRAST OF PCB ASSEMBLIES
÷
FRONT PANEL and HEAT SINK SECTIONS
Panel Base
Door Sheet
Heat Sink
No.10
No.11
No.1
BPZ30P080FMC
ABA1082
C-AMP ASSY
IBZ30P080FCC
IBZ30P080FCC
Heat Sink Holder A
No.9
Power Supply Plate
AWX7412 and AWX7397 are constructed the same except for the following :
A-PINJACK ASSY
F
B
Mark Symbol and Description
Part No.
Remarks
AWX7397 AWX7412
C1001–C1006,C1009,C1010,C1013,C1014 Not used CCCSL271J50
C1007,C1008,C1011,C1012,C1015- C1018 Not used CCCSL101J50
R1017, R1018 Not used RD1/4PU101J
Rear Panel
IBZ30P100FZK
ABA1193
Teminal
Screw
AC Cord Spacer
(HL Type Only)
No.4
AC Cord
Spacer
BBZ30P080FZK
Shield Case
Bonnet Case
Under Base
No.3
No.7
No.8
(HL Type Only)
(HL Type Only)
(HL Type Only)
No.2
No.6
No.5
AC Power Cord
AC Power Cord
BBT30P080FZK
Screw
EXPLODED VIEWS
÷
EXTERIOR SECTION
