VSX-D939TX
8
TRANS 1/LB Assy has no service parts.
TRANS 1/LB ASSY
F
N
F
V
C6002, C6003 ACG7020 ACE7014 ACG7020
C6006 CEAT470M25 CEAT221M25 CEAT470M25
R6001 RCN1080 Not used Not used
R6002 Not used RD1/4PU1R0J Not used
L6003, L6004 Not used ATX1012 Not used
J6000 Not used D20PYY0335E D20PYY0335E
T6001 ATT7043 ATT7040 ATT7041
RY6001 ASR7022 ASR1044 ASR1022
Y6003 AWG18 BOARD IN
Not used ADX7321 Not used
Y6004 AWG18 BOARD IN Not used ADX7320 Not used
Y6005 AWG18 BOARD IN Not used ADX7319 Not used
6004 AKP1053 Not used AKP1053
6001 Not used 51048-0300 51048-0300
Mark
Symbol and Description
Part No.
AWX7311 AWX7345 AWX7429
Remarks
PRIMARY ASSY
AWX7345, AWX7429 and AWX7311 are constructed the same except for the following:
PCB PARTS LIST
Mark No. Description Part No.
P-SW ASSY (AWX7330)
SWITCHES AND RELAYS
S6801 ASG1035
V
A
CAPACITORS
C6801, C6802 CGCYX103K25
OTHERS
CN6801 3P JUMPER CONNECTOR 52151-0310
Mark No. Description Part No.
AWX7677 and AWX7394 are constructed the same except for the following :
VIDEO ASSY
F
P
Mark Symbol and Description
Part No.
Remarks
AWX7394 AWX7677
IC731 NJM2279M Not used
D731 1SS355 Not used
C732, C733, C736 CKSQYB473K50 Not used
C791 CKSQYB103K Not used
R717 RS1/10S101J RS1/10S0R0J
R732- R735 RS1/10S102J Not used
CN701 52045-2645 HLEM26S-1
CN702 52045-2145 HLEM21S-1
JA705 AKN7014 Not used
