43
THE PERFECT FIT
Handlebar Adjustments
Handlebar with Riser Block
1. Remove the handlebar cover to expose
the handlebar mounting hardware.
2. Using a 1/2” wrench, loosen the two
bolts on the bottom of the riser or the
two bolts on the top of the riser,
depending on the type of adjustment
required.
3. Adjust the handlebar to the desired
angle. Be sure the handlebar, brake
lever and throttle lever operate
smoothly and do not hit the gas t ank,
windshield or any other part of the
machine when the handlebar is turned fully to the left or right.
4. Torque the handlebar adjuster block bolts to 11-13 ft. lbs. (15-17.6
Nm).
5. Replace the handlebar cover.
