Polaris Alpha User Manual

51
A-3 NTRIP Server/Caster Setup for Users With Fixed IP
Since the newest version RTKLIB v.2.4.3 provided on official website is in source code format and
compilation required Borland™ C++ builder, a pre-compiled binary executable is made available at:
https://www.polaris-gnss.com/strsvr.zip. After downloading, unzip it, “strsvr 2.4.3.exe” can be
executed directly.
After executing binary, the main STRSVR dialog screen should appear as shown in below
Figure A-3-1
1. Set up an input stream of type "Serial" and press the "Opt" button to set the input stream
options.
Figure A-3-2
2. Configure the input stream options as follows. Press the OK button to return to the STRSVR dialog
when finished.
