1.4
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
VEHICLE INFORMATION
MODEL NUMBER DESIGNATION (2015 +)
Example: R15RUE57AC
GROUP MODEL YEAR MAKE / CHASSIS CODE ENGINE CODE REGION OPTION
1st 2nd 3rd 4th* 5th* 6th* 7th* 8th* 9th 10th**
R 1
5
R U E
5
7
A C
* = digits that would transfer to 17 digit VIN and are used in digits 4-8 respectively
** = 10th digit will be used on color/featured versions of models (not including the base)
First 3 digits and 10th digit are used in model number only. They are not used with the 17 digit VIN.
Digits 1 through 8 determine Digital Wrench calibration.
VEHICLE IDENTIFICATION NUMBER (VIN) DESIGNATION (2015+)
Example: 4XARUE573FG000000
WORLD MFG. ID
VEHICLE DESCRIPTORS VEHICLE IDENTIFIERS
CHASSIS
DRIVELINE
CHASSIS
MODIFIER
ENGINE SIZE
ENGINE MODIFIER
CHECK DIGIT
MODEL YEAR *
MFG. LOCATION
INDIVIDUAL SERIAL NO.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
4 X A R U E 5 7 3 F G 0 0 0 0 0 0
* Model Year: A = 2010; B = 2011; C = 2012; D = 2013; E = 2014; F = 2015; G = 2016; H = 2017; J = 2018; K = 2019, L = 2020,
M = 2021
VIN / ENGINE NUMBER LOCATION
Whenever corresponding about a Polaris RANGER utility vehicle, be sure to refer to the Vehicle Identification Number
(VIN) and the engine model and serial number.
The VIN
q
can be found stamped on the upper frame rail on the rear LH side of the vehicle below the cargo box.
The engine model and serial number
w
can be found on a decal applied to the engine’s magneto cover.
GENERAL INFORMATION
