12
SAFETY
Safety Labels and Locations
Load/Passenger/Tire Pressure Warning
WARNING
• Never carry passengers in cargo box.
• Passengers can be thrown off. This can cause serious
injury or death.
• If total payload is greater than 500 lbs., the vehicle must
be operated in LOW range.
IMPROPER TIRE PRESSURE OR OVERLOADING CAN
CAUSE LOSS OF CONTROL RESULTING IN SERIOUS
INJURY OR DEATH.
• Reduce speed and allow greater distance for braking
when carrying cargo.
• Overloading or carrying tall, off-center, or unsecured loads will increase your risk of losing control.
Loads should be centered and carried as low as possible in box.
• For stability on rough or hilly terrain, reduce speed and cargo.
Clutch Cover Warning
WARNING
Improper service or maintenance of this PVT system can result
in vehicle damage, SEVERE INJURY or DEATH.
Always look for and remove debris inside and around clutch
and vent system when replacing belt.
Read owner’s manual or see authorized POLARIS dealer.
7177469
RANGER XP 4x4 4x4 CA CREW CA CREW
MAXIMUM CARGO BOX LOAD 1000 lbs.
(454 kg)
600 lbs.
(272 kg)
1000 lbs.
(454 kg)
600 lbs.
(272 kg)
TIRE PRESSURE IN PSI (KPa) FRONT 10 (69)
REAR 12 (83)
FRONT 10 (69)
REAR 12 (83)
FRONT 14 (96)
REAR 16 (110)
FRONT 14 (96)
REAR 16 (110)
MAXIMUM WEIGHT CAPACITY
INCLUDES WEIGHT OF
OPERATOR, PASSENGERS,
CARGO AND ACCESSORIES
1500 lbs.
(682 kg)
1100 lbs.
(499 kg)
1750 lbs.
(795 kg)
1350 lbs.
(612 kg)
Read Operation and Maintenance Manual for more detailed loading information.
RANGER XP 4x4 Hunter/NorthStar CA 4x4 Hunter/NorthStar
MAXIMUM CARGO BOX LOAD 1000 lbs. (454 kg) 600 lbs. (272 kg)
TIRE PRESSURE IN PSI (KPa) FRONT 12 (83)
REAR 12 (83)
FRONT 12 (83)
REAR 12 (83)
MAXIMUM WEIGHT CAPACITY
INCLUDES WEIGHT OF OPERATOR,
PASSENGER, CARGO AND NON-
FACTORY INSTALLED
ACCESSORIES
1275 lbs. (578 kg) 875 lbs. (397 kg)
Read Operation and Maintenance Manual for more detailed loading information.
