STARTER SOLENOID
Starter Solenoid Bench Test
Test the start solenoid by powering the solenoid using
battery voltage for a maximum of 5 seconds. With the
solenoid energized, resistance should read about 0 - 0.5
ohms between terminals (A) and (B). If resistance
measurement is out of specification, replace the starter
solenoid
Starter Solenoid Operation
To energize the Starter Solenoid the following must
occur:
• The brake must be applied to provide a ground path
via the orange wire.
• The key switch must be turned to the “start” position to
provide 12V power via the Green / White wire.
• Once the pull-in coil is energized, the solenoid
provides a current path for 12V power to reach the
starter motor.
NOTE
See “ELECTRICAL SYSTEM BREAKOUTS: Starter-
Interlock” provided in this chapter for starter
solenoid operation.
TORQUE
Starter Solenoid Cable Fasteners:
35 in-lb (4 Nm)
ELECTRICAL
