Polaris RZR S 900 2016 Service Manual

11
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
11.31
RELAY CIRCUITS
Chassis Relay
Provides power to the following systems:
• Lights (Headlights / Taillights)
• Drive (AWD)
• Accessory (12V Receptacles / Accessory Options)
WIRE COLOR FUSE BOX
PIN
FUNCTION
Red / Dark Blue
33
Coil power from EFI
B+ #2 Splice
Red 34 High side power from
Start Solenoid B+
Red / Dark
Green
37 High side output to
Chassis Splice
Grey
38
ECU controlled
ground
Fuel Pump Relay
provides power to the following system:
• Fuel Pump
WIRE COLOR FUSE BOX
PIN
FUNCTION
Red / Dark Blue 25 Coil power from EFI
B+ #2 Splice
Orange
26
High side power from
R/S B+ #1 Splice
Red / Blue
29 High side output to
fuel pump
Dark Green /
Yellow
30
ECU controlled
ground
EFI Relay
provides power to the following systems:
• Fuel Injectors
• Ignition Coil
• Fan Relay
• Fuel Pump Relay
WIRE COLOR FUSE BOX
PIN
FUNCTION
Red / White 17 Coil power from B+
Unswitched Fused #1
Splice
Red 18 High side power from
EFI fuse
Red / Dark Blue
21 High side output to
EFI B+ Splice
Dark Green /
Yellow
22 ECU controlled
ground
Fan Relay
provides power to the following system:
• Fan Motor
WIRE COLOR FUSE BOX
PIN
FUNCTION
Red / Dark Blue 9 Coil power from R/S
B+ #2 Splice
Orange / Black
10
High side power from
Fan circuit breaker
Orange / Black
13 High side output to
Fan
Orange / Black 14 ECU controlled
ground
EPS Relay (if equipped)
provides power to the following system:
• Electronic Power Steering Unit
WIRE COLOR FUSE BOX
PIN
FUNCTION
Orange
3
Coil power from R/S
B+ #2 Splice
Red 4
High side power from
EPS fuse
Orange
7
High side output to
EPS unit
Brown 8
Chassis ground
ELECTRICAL
