Lathe 960 lb net, 1020 lb shipping
Cabinet, left hand, incl. foot brake linkage
Cabinet, right hand, incl. coolant pump (option)
Power requirement 220 - 240Vac, 60 Hz, 1Ø, 12A full load
Motor TEFC type, cap start, 1.5 kW (2 HP), 1725 rpm
Work envelope
Distance between centers 36 in.
Gap insert length 9 in.
Swing over gap 17-1/2 in. diameter
Swing over bed 12 in. diameter
Swing over cross slide 7 in. diameter
Saddle travel 30-1/2 in.
Cross-slide travel 6-1/8 in.
Compound (top slide) travel 3-1/4 in.
Drive system
(High/Low belt drive with 9-speed gearbox)
Low range, rpm 65, 180, 200, 235, 330, 550, 700, 910, 1200
High range, rpm 100, 280, 300, 360, 500, 840, 1095, 1400, 1810
Carriage drive, thread cutting Leadscrew 8 tpi
Inch threads Choice of 36, from 4 to 60 tpi
Metric threads Choice of 32, from 0.4 to 7 mm pitch
Carriage drive, turning operations Choice of feed rates from 0.002 to 0.048 in./spindle rev
Cross slide drive Choice of feed rates from 0.001 to 0.009 in./spindle rev
Spindle
Chuck/faceplate attachment D1-4 Camlock
Internal taper MT5
Spindle bore Clearance for 1-1/2 in. diameter
Spindle length 15-5/8" overall
Tailstock
Internal taper MT3
Quill travel 4 in.
Work holding
Capacity, 1/8 in. to 6 in. diameter
Weight: 22 lb
Capacity: 3/8 in. to 8 in. diameter
Weight: 34 lb
Faceplate 10 in. diameter
Center rest (steady rest) capacity 3/16 to 1-1/2 in. diameter
Follower rest capacity 1/4 to 3/4 in. diameter
