Chapter
2
System
Configuration
PA
-6225
SERIES
US
ER MANUAL
Page
37
2-4-17
.
LVDS Connector
LVDS1:
LVDS Connector
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
LVDS_VCC
2
GND
3
NC
4
NC
5
GND
6
LVDS_B2_D-
7
LVDS_B2_D+
8
GND
9
LVDS_B1_D
-
10
LVDS_B1_D+
11
LVDS_B3_D+
12
LVDS_B3_D-
13
LVDS_B0_D+
14
LVDS_B0_D-
15
GND
16
L
VDS
_CL
KA_
D+
17
VDS_CLKA_D-
18
GND
19
LVDS_A2_D+
20
LVDS_A2_D-
21
GND
22
LVDS_A1_D+
23
LVDS_A1_D-
24
GND
25
LVDS_A0_D+
26
LVDS_A0_D-
27
LVDS_A3_D+
28
LVDS_A3_D-
29
LVDS_VCC
30
LVDS_VCC
2-4-
18
.
Touch Panel Connector
TOUCH1, TOUCH
2:
T
ouch panel co
nnector
PIN
ASSIGNMENT
1
LR (Low
Right)
2
LL (L
ow L
eft)
3
Prob
e
4
UR (Up Right)
5
UL (Up Left)
2
1
29
30
LVDS1
TOUCH1
TOUCH2
43
45
