64
2-7-
3.
MB
-
3012
IO1
I_B
UTTON1
1
12
1
2
MB
-
3012
MSR B
oard Co
mpo
nen
t Locations
2-7-3-
1.
Information Butt
on Reader
I_BUTTON1:
Inform
ation button reader
PIN
ASSIGNMENT
1
I_B1
2
GND
2-7-3-
2.
Output Conn
ector
IO1
:
Output w
afer
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
CLK_KB
7
RX_MSR
2
CLK_PC
8
TX_
MSR
3
DATA_KB
9
GND
4
DATA_PC
10
USB_D+_R
5
+5V
11
USB_D-
_R
6
CHASSIS GND
12
GND
1
2
I_BUTTON1
1
12
IO1
70
72
